opensnitch: GNU/Linux port of the Little Snitch application firewall

by ddos · August 16, 2024

OpenSnitch

OpenSnitch is a GNU/Linux port of the Little Snitch application firewall.

opensnitch

How Does It Work

OpenSnitch is an application-level firewall, meaning then while running, it will detect and alert the user for every outgoing connection applications he’s running are creating. This can be extremely effective to detect and block unwanted connections on your system that might be caused by a security breach, causing data exfiltration to be much harder for an attacker. In order to do that, OpenSnitch relies on NFQUEUE, an iptables target/extension which allows a userland software to intercept IP packets and either ALLOW or DROP them, once started it’ll install the following iptables rules:

OUTPUT -t mangle -m conntrack --ctstate NEW -j NFQUEUE --queue-num 0 --queue-bypass

This will use conntrack iptables extension to pass all newly created connection packets to NFQUEUE number 0 (the one OpenSnitch is listening on), and then:

INPUT --protocol udp --sport 53 -j NFQUEUE --queue-num 0 --queue-bypass

This will also redirect DNS queries to OpenSnitch, allowing the software to perform and IP -> hostname resolution without performing active DNS queries itself.

Once a new connection is detected, the software relies on the ftrace kernel extension in order to track which PID (therefore which process) is creating the connection.

If ftrace is not available for your kernel, OpenSnitch will fall back use the /proc filesystem, even if this method will also work, it’s vulnerable to application path manipulation, therefore it’s highly suggested to run OpenSnitch on a ftrace enabled kernel.

Installation

[pastacode lang=”markup” message=”” highlight=”” provider=”manual” manual=”%23%20install%20dependencies%0Asudo%20apt-get%20install%20protobuf-compiler%20libpcap-dev%20libnetfilter-queue-dev%20python3-pip%0Ago%20get%20github.com%2Fgolang%2Fprotobuf%2Fprotoc-gen-go%0Ago%20get%20-u%20github.com%2Fgolang%2Fdep%2Fcmd%2Fdep%0Apython3%20-m%20pip%20install%20–user%20grpcio-tools%0A%23%20clone%20the%20repository%20(ignore%20the%20message%20about%20no%20Go%20files%20being%20found)%0Ago%20get%20github.com%2Fevilsocket%2Fopensnitch%0Acd%20%24GOPATH%2Fsrc%2Fgithub.com%2Fevilsocket%2Fopensnitch%0A%23%20compile%20%26%26%20install%0Amake%0Asudo%20make%20install%0A%23%20enable%20opensnitchd%20as%20a%20systemd%20service%20and%20start%20the%20UI%0Asudo%20systemctl%20enable%20opensnitchd%0Asudo%20service%20opensnitchd%20start%0Aopensnitch-ui”/]

Run

Once you installed both the daemon and the UI, you can enable the opensnitchd service to run at boot time:

sudo systemctl enable opensnitchd

And run it with:

sudo service opensnitchd start

Single UI with many computers

You can also use –socket “[::]:50051” to have the UI use TCP instead of a Unix socket and run the daemon on another computer with -ui-socket “x.x.x.x:50051” (where x.x.x.x is the IP of the computer running the UI service).

Rules

Rules are stored as JSON files inside the -rule-path folder, in the simplest cast a rule looks like this:

[pastacode lang=”markup” message=”” highlight=”” provider=”manual” manual=”%7B%0A%20%20%20%22created%22%3A%20%222018-04-07T14%3A13%3A27.903996051%2B02%3A00%22%2C%0A%20%20%20%22updated%22%3A%20%222018-04-07T14%3A13%3A27.904060088%2B02%3A00%22%2C%0A%20%20%20%22name%22%3A%20%22deny-simple-www-google-analytics-l-google-com%22%2C%0A%20%20%20%22enabled%22%3A%20true%2C%0A%20%20%20%22action%22%3A%20%22deny%22%2C%0A%20%20%20%22duration%22%3A%20%22always%22%2C%0A%20%20%20%22operator%22%3A%20%7B%0A%20%20%20%20%20%22type%22%3A%20%22simple%22%2C%0A%20%20%20%20%20%22operand%22%3A%20%22dest.host%22%2C%0A%20%20%20%20%20%22data%22%3A%20%22www-google-analytics.l.google.com%22%0A%20%20%20%7D%0A%7D”/]

Field	Description
created	UTC date and time of creation.
update	UTC date and time of the last update.
name	The name of the rule.
enabled	Use to temporarily disable and enable rules without moving their files.
action	Can be deny or allow.
duration	For rules persisting on disk, this value is default to always.
operator.type	Can be simple, in which case a simple == comparison will be performed, or regexp if the data field is a regular expression to match.
operator.operand	What element of the connection to compare, can be one of: true (will always match), process.path (the path of the executable), process.command (full command line, including path and arguments), provess.env.ENV_VAR_NAME (use the value of an environment variable of the process given its name), user.id, dest.ip, dest.host or dest.port.
operator. data	The data to compare the operand to, can be a regular expression if type is regexp.
